Centrifugal pumps with magnetic drive

centrifugalPUMP - Series MP

Features

  • Self-priming with the advantages of a magnetic-drive centrifugal pump
  • Powerful - despite low energy consumption
  • Fast suction - 5.5 meters in 90 seconds
  • Leakage free and low maintenance costs



Applications

  • Wagon emptying
  • Tankers emptying
  • Emptying double-walled containers
  • Transfer from storage to consumption tank
  • Underground tanks
Magnetgekuppelte Kreiselpumpe MP

Standard versions

MP10​
H (max.): 14 m
Q (max.): 12 m3/h

MP11
H (max.): 21 m
Q (max.): 23 m3/h

MP15
H (max.): 23 m
Q (max.): 25 m3/h

MP22
H (max.): 37 m
Q (max.): 46 m3/h

Q (max.) at 50Hz

Technical specifications

  • Threaded connection or flange
  • Materials: Polypropylene or PVDF
  • Max. viscosity above 50cP
  • Max. temperature: 82° C (PP) 104° C (PVDF)
